·Large diaphragm for smooth, natural sound and low noise
·High SPL handling and wide dynamic range provide unmatched versatility
·Custom shock mount provides superior isolation
·Switchable 80 Hz high-pass filter and 10 dB pad
·Cardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source
·Includes custom shock mount & protective pouch
SPECIFICATIONS
ELEMENT Fixed-charge back plate, permanently polarized condenser
POLAR PATTERN Cardioid
FREQUENCY RESPONSE 20-20,000 Hz
LOW FREQUENCY ROLL-OFF 80 Hz, 12 dB/octave
OPEN CIRCUIT SENSITIVITY -33 dB (22.4 mV) re 1V at 1 Pa
IMPEDANCE 120 ohms
MAXIMUM INPUT SOUND LEVEL 148 dB SPL, 1 kHz at 1% T.H.D.; 158 dB SPL, with 10 dB pad (nominal)
NOISE 12 dB SPL
DYNAMIC RANGE (typical) 136 dB, 1 kHz at Max SPL
SIGNAL-TO-NOISE RATIO 82 dB, 1 kHz at 1 Pa
PHANTOM POWER REQUIREMENTS 11-52V DC, 3.8 mA typical
SWITCHES Flat, roll-off; 10 dB pad (nominal)
WEIGHT 403 g (14.2 oz)
DIMENSIONS 170.0 mm (6.69") long, 52.0 mm (2.05") maximum body diameter
OUTPUT CONNECTOR Integral 3-pin XLRM-type
ACCESSORIES FURNISHED AT8458 shock mount for 5/8"-27 threaded stands; 5/8"-27 to 3/8"-16 threaded adapter; soft protective pouch
AUDIO-TECHNICA CASE STYLE R5
